Cheer (win)

The win of the nine game cycles: a little spring with both arms up, two pumps of the fists and a happy face, 1.2 seconds from start to finish, for a game to play the instant a character wins or clears something.

A cartoon person and a dog with arms raised overhead, mid-cheer, a happy face.

Use it in a cartoon Open it in the block editor The pack file (JSON)

What it is for

Cheer (win) is the win of the nine game cycles: a game plays it the instant a character wins, clears a level or completes whatever it is working toward, a short burst, 1.2 seconds, that plays once and ends back at a standing pose.

The principle it shows: anticipation and follow-through

A small spring up (legs bending 18 degrees, arms swinging back) comes first and primes the cheer before the arms ever go up, the same storing-of-energy a jump's crouch does. After the main pump of fists is done, the move does not simply stop: a quarter-turn-offset wave keeps both forearms snapping for half a second, the energy spent in diminishing little pumps rather than cut off dead, before easing all the way back to standing.

The program, line by line

settings: h = 540, leg = 0.24
when it starts
  show the side view
  look happy
  at the same time:
    — 1:
      glide hips 0, left leg 18, right leg 18, left shin 36, right shin 36, left foot 18, right foot 18, left arm -20, right arm -20, left forearm 20, right forearm 20 over 0.14 s (out)
    — 2:
      set dx 0, dy 0
      for 0.14 s:
        dy follows (h*leg/2*(2 - cos(((0 + 18*sin((min(local/0.14, 1))*pi/2)))*pi/180) - cos((((0 + 18*sin((min(local/0.14, 1))*pi/2))) - ((0 + 36*sin((min(local/0.14, 1))*pi/2))))*pi/180)))
        dx follows (-h*leg/2*(sin(((0 + 18*sin((min(local/0.14, 1))*pi/2)))*pi/180) + sin((((0 + 18*sin((min(local/0.14, 1))*pi/2))) - ((0 + 36*sin((min(local/0.14, 1))*pi/2))))*pi/180)))
  set dx (-h*leg/2*(sin((18)*pi/180) + sin(((18) - (36))*pi/180))), dy (h*leg/2*(2 - cos((18)*pi/180) - cos(((18) - (36))*pi/180)))
  at the same time:
    — 1:
      glide hips 0, left leg 0, right leg 0, left shin 0, right shin 0, left foot 0, right foot 0, right arm 90, left arm 110, left forearm 25, right forearm 25 over 0.06 s (in)
    — 2:
      set dx 0, dy 0
      for 0.06 s:
        dy follows (h*leg/2*(2 - cos(((18 + -18*pow(min(local/0.06, 1), 2)))*pi/180) - cos((((18 + -18*pow(min(local/0.06, 1), 2))) - ((36 + -36*pow(min(local/0.06, 1), 2))))*pi/180)))
        dx follows (-h*leg/2*(sin(((18 + -18*pow(min(local/0.06, 1), 2)))*pi/180) + sin((((18 + -18*pow(min(local/0.06, 1), 2))) - ((36 + -36*pow(min(local/0.06, 1), 2))))*pi/180)))
  set dx (-h*leg/2*(sin((0)*pi/180) + sin(((0) - (0))*pi/180))), dy (h*leg/2*(2 - cos((0)*pi/180) - cos(((0) - (0))*pi/180)))
  glide dy (-0.045*h), left foot -8, right foot -8, right arm 132, left arm 165, mouth 0.6 over 0.12 s (out)
  glide dy 0, left foot 0, right foot 0 over 0.1 s (in)
  at the same time:
    — 1:
      glide hips 0, left leg 12, right leg 12, left shin 24, right shin 24, left foot 12, right foot 12 over 0.08 s (out)
    — 2:
      set dx 0, dy 0
      for 0.08 s:
        dy follows (h*leg/2*(2 - cos(((0 + 12*sin((min(local/0.08, 1))*pi/2)))*pi/180) - cos((((0 + 12*sin((min(local/0.08, 1))*pi/2))) - ((0 + 24*sin((min(local/0.08, 1))*pi/2))))*pi/180)))
        dx follows (-h*leg/2*(sin(((0 + 12*sin((min(local/0.08, 1))*pi/2)))*pi/180) + sin((((0 + 12*sin((min(local/0.08, 1))*pi/2))) - ((0 + 24*sin((min(local/0.08, 1))*pi/2))))*pi/180)))
  set dx (-h*leg/2*(sin((12)*pi/180) + sin(((12) - (24))*pi/180))), dy (h*leg/2*(2 - cos((12)*pi/180) - cos(((12) - (24))*pi/180)))
  for 0.5 s:
    sin wave on left arm · every 0.25 s · amp 12
    sin wave on right arm · every 0.25 s · amp 12
    sin wave on forearms · every 0.25 s · amp 22 · phase 1.5707963267948966
  at the same time:
    — 1:
      glide hips 0, left leg 0, right leg 0, left shin 0, right shin 0, left foot 0, right foot 0, left arm 0, right arm 0, left forearm 0, right forearm 0, mouth 0 over 0.2 s (smooth)
    — 2:
      set dx 0, dy 0
      for 0.2 s:
        dy follows (h*leg/2*(2 - cos(((12 + -12*smoothstep(min(local/0.2, 1))))*pi/180) - cos((((12 + -12*smoothstep(min(local/0.2, 1)))) - ((24 + -24*smoothstep(min(local/0.2, 1)))))*pi/180)))
        dx follows (-h*leg/2*(sin(((12 + -12*smoothstep(min(local/0.2, 1))))*pi/180) + sin((((12 + -12*smoothstep(min(local/0.2, 1)))) - ((24 + -24*smoothstep(min(local/0.2, 1)))))*pi/180)))
  set dx (-h*leg/2*(sin((0)*pi/180) + sin(((0) - (0))*pi/180))), dy (h*leg/2*(2 - cos((0)*pi/180) - cos(((0) - (0))*pi/180)))

show the side view — the move is drawn in profile.
look happy — the face changes to its happy expression for the whole move.
at the same time: — a small spring: the legs bend 18 degrees and the arms swing back 20 degrees, over 0.14 seconds, the body's position kept in step so the feet do not slide.
set dx …, dy … — locks the body to match that spring's pose.
at the same time: — the legs straighten back out while the arms swing up past 90 and 110 degrees, over 0.06 seconds: the arms thrown overhead.
set dx …, dy … — locks the body again.
glide dy (-0.045*h), left foot -8, right foot -8, right arm 132, left arm 165, mouth 0.6 over 0.12 s (out) — the first pump: the body lifts a little, the arms reach further up and the mouth opens in a shout.
glide dy 0, left foot 0, right foot 0 over 0.1 s (in) — settles back down from that first pump.
at the same time: — a small second crouch, the legs bending 12 degrees again, over 0.08 seconds, feet kept planted.
set dx …, dy … — locks the body once more.
for 0.5 s: — both arms wave 12 degrees and both forearms wave 22 degrees together, a quarter-turn out of phase with the arms: two quick pumps of the fists.
at the same time: — everything eases back to a standing pose over 0.2 seconds, feet kept planted as it goes.
set dx 0, dy 0 — back to standing exactly on the spot.

Written out in full, exactly as the engine prints them:

h*leg/2*(2 - cos(((0 + 18*sin((min(local/0.14, 1))*pi/2)))*pi/180) - cos((((0 + 18*sin((min(local/0.14, 1))*pi/2))) - ((0 + 36*sin((min(local/0.14, 1))*pi/2))))*pi/180))

-h*leg/2*(sin(((0 + 18*sin((min(local/0.14, 1))*pi/2)))*pi/180) + sin((((0 + 18*sin((min(local/0.14, 1))*pi/2))) - ((0 + 36*sin((min(local/0.14, 1))*pi/2))))*pi/180))

-h*leg/2*(sin((18)*pi/180) + sin(((18) - (36))*pi/180))

h*leg/2*(2 - cos((18)*pi/180) - cos(((18) - (36))*pi/180))

h*leg/2*(2 - cos(((18 + -18*pow(min(local/0.06, 1), 2)))*pi/180) - cos((((18 + -18*pow(min(local/0.06, 1), 2))) - ((36 + -36*pow(min(local/0.06, 1), 2))))*pi/180))

-h*leg/2*(sin(((18 + -18*pow(min(local/0.06, 1), 2)))*pi/180) + sin((((18 + -18*pow(min(local/0.06, 1), 2))) - ((36 + -36*pow(min(local/0.06, 1), 2))))*pi/180))

-h*leg/2*(sin((0)*pi/180) + sin(((0) - (0))*pi/180))

h*leg/2*(2 - cos((0)*pi/180) - cos(((0) - (0))*pi/180))

h*leg/2*(2 - cos(((0 + 12*sin((min(local/0.08, 1))*pi/2)))*pi/180) - cos((((0 + 12*sin((min(local/0.08, 1))*pi/2))) - ((0 + 24*sin((min(local/0.08, 1))*pi/2))))*pi/180))

-h*leg/2*(sin(((0 + 12*sin((min(local/0.08, 1))*pi/2)))*pi/180) + sin((((0 + 12*sin((min(local/0.08, 1))*pi/2))) - ((0 + 24*sin((min(local/0.08, 1))*pi/2))))*pi/180))

-h*leg/2*(sin((12)*pi/180) + sin(((12) - (24))*pi/180))

h*leg/2*(2 - cos((12)*pi/180) - cos(((12) - (24))*pi/180))

h*leg/2*(2 - cos(((12 + -12*smoothstep(min(local/0.2, 1))))*pi/180) - cos((((12 + -12*smoothstep(min(local/0.2, 1)))) - ((24 + -24*smoothstep(min(local/0.2, 1)))))*pi/180))

-h*leg/2*(sin(((12 + -12*smoothstep(min(local/0.2, 1))))*pi/180) + sin((((12 + -12*smoothstep(min(local/0.2, 1)))) - ((24 + -24*smoothstep(min(local/0.2, 1)))))*pi/180))

Try this

Keep the fists pumping for a full second instead of half a second. Two more pumps fit in before the cheer eases off, a longer celebration for a bigger win.
In the program: for · s 0.5 → 1
Open the mouth all the way (mouth 1 instead of 0.6) at the first fist pump. The cheer reads as a full shout instead of a grin.
In the program: ramp · to.mouth 0.6 → 1

How it differs from Flinch (hurt) and Jump for joy

Flinch (hurt) is the opposite reaction on the same cycle set, a recoil rather than a spring, and it is a third as long. Jump for joy is a hand-built celebration meant to play once in a cartoon scene; Cheer (win) is the game cycles' own short win state, tuned to start and end cleanly between other cycles.

Works on

Worked out by the build: it plays the move in the engine on each body and checks what moves on screen. Nobody types this table.
Body	Moves?	What moves
2 legs (a person)	yes	whole body, turns, arms, legs
4 legs (a dog)	yes	whole body, front legs, back legs
no legs (the monster with no legs)	yes	whole body, turns, arms

c4c:beh:cycle_win · version 1.0.0 · c4c-free · by Jabbertoon
