Sit (four legs)
Staying seated for four legs: the rear stays down on the folded back legs, breathing, blinking and wagging its tail now and then, looping every 4 seconds until a game stands the character back up.
Use it in a cartoonOpen it in the block editorThe pack file (JSON)
What it is for
Sit (four legs) is the sit of the nine game cycles, written for the fours set: it holds the pose Sit down (four legs) settles into, breathing, blinking and wagging its tail now and then, looping every 4 seconds for as long as a game leaves the character there.
The principle it shows: overlapping action
The breath and the head's own sway share the same four-second period but start at a different point in it, the same layering the upright sit uses. The tail wag runs on its own separate one-second rhythm, a detail the upright sit has no equivalent of at all, since it is the one part of a dog's or a cat's body that keeps moving even in an otherwise quiet hold.
The program, line by line
settings: h = 540, leg = 0.33, on = 0
when it starts
show the side view
set torso 34, head -16, tail 16, dy (-0.01*h)
sin wave on sy · every 4 s · amp 0.01
sin wave on head · every 4 s · amp 3 · phase 0.8
sin wave on tail · every 1 s · amp 10
possin wave on blink · every 4 s · amp 1 · phase 1.2 · power 40show the side view— the move is drawn in profile.set torso 34, head -16, tail 16, dy (-0.01*h)— the settled sitting pose: the rear down, the head dipped and the tail lifted.sin wave on sy · every 4 s · amp 0.01— a slow breath, the body stretching a little.sin wave on head · every 4 s · amp 3 · phase 0.8— the head drifts a little, offset from the breath.sin wave on tail · every 1 s · amp 10— the tail wags, its own faster rhythm.possin wave on blink · every 4 s · amp 1 · phase 1.2 · power 40— a sharp blink once every 4 seconds.
Try this
Wag the tail 20 degrees each way instead of 10. The settled hold reads as a visibly happier, more eager sit.
In the program:
wave · amp10→20Breathe more than twice as deep, 0.01 to 0.025. The seated hold reads as a slow, deliberate breath rather than ordinary quiet rest.
In the program:
wave · amp0.01→0.025
How it differs from Sit down (four legs) and Stand up (four legs)
Sit down (four legs) is the motion of settling into this pose. Stand up (four legs) is what a game switches to when it is time to leave this pose behind.
Works on
| Body | Moves? | What moves |
|---|---|---|
| 2 legs (a person) | yes | whole body, turns, body, head, arms |
| 4 legs (a dog) | yes | whole body, body, head, back legs, tail, ears |
| no legs (the monster with no legs) | yes | whole body, turns, body, arms, tail, ears |
